Dakar Proto for Sale - €100,000 / £90,000

Dakar T1.1 4X4 Prototype based on a McRae Enduro Chassis (first in class 2009 Dakar Rally, as Featured in Autosport, Motorport News , Autocar and Total Off Road Magazine).

Total bare metal rebuild by MRacing (X-Raid Portugal) from the ground up, modified to meet current 2.9m FIA wheelbase distance, developed with MOTEC, further development and current maintenance by MDVSE UK.

Perfect car for the Rally Raid / Baja / Cross Country amateur / enthusiast. Maximum fun & reliability with minimal cost due to hybrid use of standard (Land Rover & BMW) parts with key racing components. Land Rover diffs, engine mounts, steering rack, bearings, bushes. BMW engine. SADEV Gearbox , AP Racing Clutch & Brakes, Reiger Suspension & hydraulic jacks.

Under current owner taken part in events all over the world including Saudi Arabia, Algeria, Morocco, Iceland, Spain, Portugal and United Kingdom for the past 7 years.

For Further info phone / whatsapp: +44 7438 321 702

Documentation

Fully and 100% genuinely documented, Insured, Road Taxed and MOT yearly in the UK, including:

International FIA Passport (aka Gold Book), with 7 FIA race scrutineering & stamps between 2018 and 2023, including:
- Baja Aragon / Spain (2018, 2019, 2021,2022, 2023)
- Baja Portalegre / Portugal (2018)
- Dakar (FIA) Rally (2022)
Portuguese FPAK Passport, (with national races in Portugal)
Spanish RFEDA Passport
MSA Safety Roll Cage
FIA FT3 Fuel Cell Certificate of Conformance, valid till 04/2027
UK DVLA V5C Registration Document under owners name & address
UK DVLA Number Plate Authorisation Certificate

Chassis / Body

T45 Steel Tubular Space Frame Chassis, with bolt on Front and Rear Subframes and Composite lightweight body panels.

Engine

3.0L BMW M57 Turbo Diesel, BOSCH ECU, BOSCH Solenoid Injectors and GARRETT Vacuum actuated Turbo, currently programmed with standard BMW power 260hp / 540 Newtons torque, for absolute maximum reliability on long Rally Raids. Extremely low fuel consumption.

2 x BOSCH fuel pumps for redundancy. 245L Advanced Fuel Systems Fuel Cell with 3L swirl pot to eliminate fuel starvation on steep climbs with low / near empty tank.

Driveline

SADEV SC90-24 6 speed sequential gear/transfer box, with centre lock
GKN Motorsport M300 drive shafts
Land Rover Front Differential – Free
Land Rover Rear Differential with Ricardo lockable inner

Brake / Clutch

AP Racing Triple Plate Clutch with AP Racing brakes, same set up front and back:

AP Racing Brake discs
AP Racing 6 piston Rally Raid Callipers
FERODO Racing brake pads

Suspension

Independent double wishbone Front and Rear, same all around
Twin REIGER dampers per wheel, same all around

Cooling

Front Mounted Intercooler
Twin Front Mounted Oil Cooler
Mid / Rear mounted Fuel cooler
Mid / Rear Mounted Water cooler / radiator
Supplementary water pump

MOTEC

Absolute minimal cabling, relay and fuse free. Full data logging, temperatures, pressures, G-Forces, etc… holding multiple races in memory. MOTEC logic => car looks after itself, turning fans / pumps on / off by itsel as required, the driver just drives….
